Iron ore crushing line

2024-05-19 10:18:59

Iron ore crushing production line introduction

Yuyuan can produce iron ore crushing processing production line equipment, and provide you with technical support, iron ore crushing processing is usually composed of vibration feeder, jaw crusher, hydraulic cone crusher, vibrating screen, belt conveyor and other equipment; Suitable for iron ore, gold and other non-ferrous mineral processing; The design output is generally 50-1000 tons/hour.

  • [Applicable materials] : Nonferrous metal mineral processing such as iron ore and gold ore
  • 【 Application field 】 : Mineral processing
  • [Equipment configuration] : jaw crusher, cone breaking, vibrating screen, belt conveyor



Introduction to iron ore

There are more than ten kinds of iron minerals in nature. The iron ores of industrial significance are mainly magnetite, hematite and pseudophematite. Followed by siderite, limonite and so on. Iron ore is an important raw material for iron and steel production enterprises. Natural iron ore is gradually selected by crushing, grinding, magnetic separation, flotation, gravity separation and other procedures.

Introduction to iron ore

Basalt sand production flow chart

Iron ore dressing process flow

Iron ore beneficiation, according to the type and nature of the ore, there can be a variety of different processes. The concentrator generally adopts three crushing processes of coarse breaking, medium breaking and fine breaking to break iron ore. Coarse break multi-purpose jaw crusher, medium and fine crusher using cone crusher. Through the coarse broken ore, and then through the medium and fine crushing into the material size suitable for entering the ball mill.
The iron ore is evenly sent to the jaw crusher for rough breaking by the vibration feeder, the rough broken material is sent to the rough cone breaking by the belt conveyor for further crushing, the broken material is transported to the vibrating screen for screening, and the material that meets the finished particle size requirements is transported to the finished material pile by the belt conveyor; The material that does not meet the particle size requirements of the finished product is returned to the vibrating screen for medium crushing or fine cone breaking processing to form a closed cycle. The finished product size can be combined and graded according to the needs of users.



Iron ore dressing crushing process performance

The iron ore dressing crushing production line has high degree of automation, high crushing rate, low operating cost, energy saving and environmental protection, and fine particle size. Yuyuan provides customers with process plan and technical support, and also designs non-standard supporting parts according to customers’ actual installation conditions.



Technical description:

1. This process is designed according to the parameters provided by the customer. This flowchart is for reference only.

2. The actual construction should be adjusted according to the terrain.

3. The mud content of the material can not exceed 10%, and the mud content will have an important impact on the output, equipment and process.

4. Yuyuan Machinery can provide process plan and technical support according to the actual requirements of customers, and can also design non-standard supporting parts according to the actual installation conditions of customers.
